If you have done the following runmqsc command to display all local queues filtering by current queue depth of a queue manager:

DIS QL(*) WHERE (CURDEPTH GT 0)

And you wanted to do the same thing via a program, here is a fully functioning Java MQ example that will connect to a remote queue manager, issue a PCF “Inquire Queue” command filtering the current queue depth (CURDEPTH), get the PCF response messages, loop through the PCF responses and output the information. You can download the source code from here.

For more information about the PCF “Inquire Queue” command, go to MQ KnowLedge Center here.

import java.io.IOException;
import java.text.SimpleDateFormat;
import java.util.Date;
import java.util.Hashtable;

import com.ibm.mq.MQException;
import com.ibm.mq.MQQueueManager;
import com.ibm.mq.constants.CMQC;
import com.ibm.mq.constants.CMQCFC;
import com.ibm.mq.headers.MQDataException;
import com.ibm.mq.headers.pcf.PCFMessage;
import com.ibm.mq.headers.pcf.PCFMessageAgent;

/**
 * Program Name
 *  MQListQueueWithFilter01
 *
 * Description
 *  This java class issues a PCF "inquire queue" request message for all ("*") local queues
 *  with a queue depth greater than 0 (zero) of a remote queue manager.
 *
 *  This PCF code is equivalent to issuing the runmqsc command of:
 *     DIS QL(*) WHERE (CURDEPTH GT 0)
 *
 * Sample Command Line Parameters
 *  -m MQA1 -h 127.0.0.1 -p 1414 -c TEST.CHL -u UserID -x Password
 *
 * @author Roger Lacroix
 */
public class MQListQueueWithFilter01
{
   private static final SimpleDateFormat  LOGGER_TIMESTAMP = new SimpleDateFormat("yyyy/MM/dd HH:mm:ss.SSS");

   private Hashtable<String,String> params;
   private Hashtable<String,Object> mqht;
   private String qMgrName;

   public MQListQueueWithFilter01()
   {
      super();
      params = new Hashtable<String,String>();
      mqht = new Hashtable<String,Object>();
   }

   /**
    * Make sure the required parameters are present.
    * @return true/false
    */
   private boolean allParamsPresent()
   {
      boolean b = params.containsKey("-h") && params.containsKey("-p") &&
                  params.containsKey("-c") && params.containsKey("-m") &&
                  params.containsKey("-u") && params.containsKey("-x");
      if (b)
      {
         try
         {
            Integer.parseInt((String) params.get("-p"));
         }
         catch (NumberFormatException e)
         {
            b = false;
         }
      }

      return b;
   }

   /**
    * Extract the command-line parameters and initialize the MQ HashTable.
    * @param args
    * @throws IllegalArgumentException
    */
   private void init(String[] args) throws IllegalArgumentException
   {
      int port = 1414;
      if (args.length > 0 && (args.length % 2) == 0)
      {
         for (int i = 0; i < args.length; i += 2)
         {
            params.put(args[i], args[i + 1]);
         }
      }
      else
      {
         throw new IllegalArgumentException();
      }

      if (allParamsPresent())
      {
         qMgrName = (String) params.get("-m");

         try
         {
            port = Integer.parseInt((String) params.get("-p"));
         }
         catch (NumberFormatException e)
         {
            port = 1414;
         }

         mqht.put(CMQC.CHANNEL_PROPERTY, params.get("-c"));
         mqht.put(CMQC.HOST_NAME_PROPERTY, params.get("-h"));
         mqht.put(CMQC.PORT_PROPERTY, new Integer(port));
         mqht.put(CMQC.USER_ID_PROPERTY, params.get("-u"));
         mqht.put(CMQC.PASSWORD_PROPERTY, params.get("-x"));

         // I don't want to see MQ exceptions at the console.
         MQException.log = null;
      }
      else
      {
         throw new IllegalArgumentException();
      }
   }

   /**
    * Handle connecting to the queue manager, issuing PCF command then
    * looping through PCF response messages and disconnecting from
    * the queue manager.
    */
   private void doPCF()
   {
      MQQueueManager qMgr = null;
      PCFMessageAgent agent = null;
      PCFMessage   request = null;
      PCFMessage[] responses = null;

      try
      {
         qMgr = new MQQueueManager(qMgrName, mqht);
         MQListQueueWithFilter01.logger("successfully connected to "+ qMgrName);

         agent = new PCFMessageAgent(qMgr);
         MQListQueueWithFilter01.logger("successfully created agent");

         // https://www.ibm.com/support/knowledgecenter/en/SSFKSJ_9.1.0/com.ibm.mq.ref.adm.doc/q087800_.htm
         request = new PCFMessage(CMQCFC.MQCMD_INQUIRE_Q);

         /**
          * You can explicitly set a queue name like "TEST.Q1" or
          * use a wild card like "TEST.*"
          */
         request.addParameter(CMQC.MQCA_Q_NAME, "*");

         // Add parameter to request only local queues
         request.addParameter(CMQC.MQIA_Q_TYPE, CMQC.MQQT_LOCAL);

         // Add parameter to request only queue name and current depth
         request.addParameter(CMQCFC.MQIACF_Q_ATTRS, new int [] {
                                                                  CMQC.MQCA_Q_NAME,
                                                                  CMQC.MQIA_CURRENT_Q_DEPTH
                                                                });

         // Add filter to only return responses with a queue depth greater than 0 (zero)  i.e. non-zero queue depth
         request.addFilterParameter(CMQC.MQIA_CURRENT_Q_DEPTH, CMQCFC.MQCFOP_GREATER, 0);

         responses = agent.send(request);

         MQListQueueWithFilter01.logger("responses.length="+responses.length);

         for (int i = 0; i < responses.length; i++)
         {
            if ( ((responses[i]).getCompCode() == CMQC.MQCC_OK) &&
                 ((responses[i]).getParameterValue(CMQC.MQCA_Q_NAME) != null) )
            {
               String name = responses[i].getStringParameterValue(CMQC.MQCA_Q_NAME);
               if (name != null)
                  name = name.trim();

               int depth = responses[i].getIntParameterValue(CMQC.MQIA_CURRENT_Q_DEPTH);

               MQListQueueWithFilter01.logger("Name="+name + " : depth="+depth);
            }
         }
      }
      catch (MQException e)
      {
         MQListQueueWithFilter01.logger("CC=" +e.completionCode + " : RC=" + e.reasonCode);
      }
      catch (IOException e)
      {
         MQListQueueWithFilter01.logger("IOException:" +e.getLocalizedMessage());
      }
      catch (MQDataException e)
      {
         MQListQueueWithFilter01.logger("MQDataException:" +e.getLocalizedMessage());
      }
      finally
      {
         try
         {
            if (agent != null)
            {
               agent.disconnect();
               MQListQueueWithFilter01.logger("disconnected from agent");
            }
         }
         catch (MQDataException e)
         {
            MQListQueueWithFilter01.logger("CC=" +e.completionCode + " : RC=" + e.reasonCode);
         }

         try
         {
            if (qMgr != null)
            {
               qMgr.disconnect();
               MQListQueueWithFilter01.logger("disconnected from "+ qMgrName);
            }
         }
         catch (MQException e)
         {
            MQListQueueWithFilter01.logger("CC=" +e.completionCode + " : RC=" + e.reasonCode);
         }
      }
   }

   /**
    * A simple logger method
    * @param data
    */
   public static void logger(String data)
   {
      String className = Thread.currentThread().getStackTrace()[2].getClassName();

      // Remove the package info.
      if ( (className != null) && (className.lastIndexOf('.') != -1) )
         className = className.substring(className.lastIndexOf('.')+1);

      System.out.println(LOGGER_TIMESTAMP.format(new Date())+" "+className+": "+Thread.currentThread().getStackTrace()[2].getMethodName()+": "+data);
   }

   public static void main(String[] args)
   {
      MQListQueueWithFilter01 mqlqs = new MQListQueueWithFilter01();

      try
      {
         mqlqs.init(args);
         mqlqs.doPCF();
      }
      catch (IllegalArgumentException e)
      {
         MQListQueueWithFilter01.logger("Usage: java MQListQueueWithFilter01 -m QueueManagerName -h host -p port -c channel -u UserID -x Password");
         System.exit(1);
      }

      System.exit(0);
   }
}

Regards,
Roger Lacroix
Capitalware Inc.

If you have done the following runmqsc command to display all local queues with attributes of a queue manager:

DIS QL(*) ALL

And you wanted to do the same thing via a program, here is a fully functioning Java MQ example that will connect to a remote queue manager, issue a PCF “Inquire Queue” command, get the PCF response messages, loop through the PCF responses and output the information. You can download the source code from here.

For more information about the PCF “Inquire Queue” command, go to MQ KnowLedge Center here.

import java.io.IOException;
import java.text.SimpleDateFormat;
import java.util.Date;
import java.util.Hashtable;

import com.ibm.mq.MQException;
import com.ibm.mq.MQQueueManager;
import com.ibm.mq.constants.CMQC;
import com.ibm.mq.constants.CMQCFC;
import com.ibm.mq.headers.MQDataException;
import com.ibm.mq.headers.pcf.PCFMessage;
import com.ibm.mq.headers.pcf.PCFMessageAgent;

/**
 * Program Name
 *  MQListQueueAttributes01
 *
 * Description
 *  This java class issues a PCF "inquire queue" request message for all ("*") local queues
 *  of a remote queue manager.
 *
 *  This PCF code is equivalent to issuing the runmqsc command of:
 *     DIS QL(*) ALL
 *
 * Sample Command Line Parameters
 *  -m MQA1 -h 127.0.0.1 -p 1414 -c TEST.CHL -u UserID -x Password
 *
 * @author Roger Lacroix
 */
public class MQListQueueAttributes01
{
   private static final SimpleDateFormat  LOGGER_TIMESTAMP = new SimpleDateFormat("yyyy/MM/dd HH:mm:ss.SSS");

   private Hashtable<String,String> params;
   private Hashtable<String,Object> mqht;
   private String qMgrName;

   public MQListQueueAttributes01()
   {
      super();
      params = new Hashtable<String,String>();
      mqht = new Hashtable<String,Object>();
   }

   /**
    * Make sure the required parameters are present.
    * @return true/false
    */
   private boolean allParamsPresent()
   {
      boolean b = params.containsKey("-h") && params.containsKey("-p") &&
                  params.containsKey("-c") && params.containsKey("-m") &&
                  params.containsKey("-u") && params.containsKey("-x");
      if (b)
      {
         try
         {
            Integer.parseInt((String) params.get("-p"));
         }
         catch (NumberFormatException e)
         {
            b = false;
         }
      }

      return b;
   }

   /**
    * Extract the command-line parameters and initialize the MQ HashTable.
    * @param args
    * @throws IllegalArgumentException
    */
   private void init(String[] args) throws IllegalArgumentException
   {
      int port = 1414;
      if (args.length > 0 && (args.length % 2) == 0)
      {
         for (int i = 0; i < args.length; i += 2)
         {
            params.put(args[i], args[i + 1]);
         }
      }
      else
      {
         throw new IllegalArgumentException();
      }

      if (allParamsPresent())
      {
         qMgrName = (String) params.get("-m");

         try
         {
            port = Integer.parseInt((String) params.get("-p"));
         }
         catch (NumberFormatException e)
         {
            port = 1414;
         }

         mqht.put(CMQC.CHANNEL_PROPERTY, params.get("-c"));
         mqht.put(CMQC.HOST_NAME_PROPERTY, params.get("-h"));
         mqht.put(CMQC.PORT_PROPERTY, new Integer(port));
         mqht.put(CMQC.USER_ID_PROPERTY, params.get("-u"));
         mqht.put(CMQC.PASSWORD_PROPERTY, params.get("-x"));

         // I don't want to see MQ exceptions at the console.
         MQException.log = null;
      }
      else
      {
         throw new IllegalArgumentException();
      }
   }

   /**
    * Handle connecting to the queue manager, issuing PCF command then
    * looping through PCF response messages and disconnecting from
    * the queue manager.
    */
   private void doPCF()
   {
      MQQueueManager qMgr = null;
      PCFMessageAgent agent = null;
      PCFMessage   request = null;
      PCFMessage[] responses = null;

      try
      {
         qMgr = new MQQueueManager(qMgrName, mqht);
         MQListQueueAttributes01.logger("successfully connected to "+ qMgrName);

         agent = new PCFMessageAgent(qMgr);
         MQListQueueAttributes01.logger("successfully created agent");

         // https://www.ibm.com/support/knowledgecenter/en/SSFKSJ_9.1.0/com.ibm.mq.ref.adm.doc/q087800_.htm
         request = new PCFMessage(CMQCFC.MQCMD_INQUIRE_Q);

         /**
          * You can explicitly set a queue name like "TEST.Q1" or
          * use a wild card like "TEST.*"
          */
         request.addParameter(CMQC.MQCA_Q_NAME, "*");

         // Add parameter to request only local queues
         request.addParameter(CMQC.MQIA_Q_TYPE, CMQC.MQQT_LOCAL);

         // Add parameter to request all of the attributes of the queue
         request.addParameter(CMQCFC.MQIACF_Q_ATTRS, new int [] { CMQCFC.MQIACF_ALL });

         responses = agent.send(request);

         MQListQueueAttributes01.logger("responses.length="+responses.length);

         for (int i = 0; i < responses.length; i++)
         {
            if ( ((responses[i]).getCompCode() == CMQC.MQCC_OK) &&
                 ((responses[i]).getParameterValue(CMQC.MQCA_Q_NAME) != null) )
            {
               String name = responses[i].getStringParameterValue(CMQC.MQCA_Q_NAME);
               if (name != null)
                  name = name.trim();

               int depth = responses[i].getIntParameterValue(CMQC.MQIA_CURRENT_Q_DEPTH);
               int maxDepth = responses[i].getIntParameterValue(CMQC.MQIA_MAX_Q_DEPTH);

               // many, many attributes can be listed - see web page mentioned above.

               MQListQueueAttributes01.logger("Name="+name + " : depth="+depth + " : max_depth="+maxDepth);
            }
         }
      }
      catch (MQException e)
      {
         MQListQueueAttributes01.logger("CC=" +e.completionCode + " : RC=" + e.reasonCode);
      }
      catch (IOException e)
      {
         MQListQueueAttributes01.logger("IOException:" +e.getLocalizedMessage());
      }
      catch (MQDataException e)
      {
         MQListQueueAttributes01.logger("MQDataException:" +e.getLocalizedMessage());
      }
      finally
      {
         try
         {
            if (agent != null)
            {
               agent.disconnect();
               MQListQueueAttributes01.logger("disconnected from agent");
            }
         }
         catch (MQDataException e)
         {
            MQListQueueAttributes01.logger("CC=" +e.completionCode + " : RC=" + e.reasonCode);
         }

         try
         {
            if (qMgr != null)
            {
               qMgr.disconnect();
               MQListQueueAttributes01.logger("disconnected from "+ qMgrName);
            }
         }
         catch (MQException e)
         {
            MQListQueueAttributes01.logger("CC=" +e.completionCode + " : RC=" + e.reasonCode);
         }
      }
   }

   /**
    * A simple logger method
    * @param data
    */
   public static void logger(String data)
   {
      String className = Thread.currentThread().getStackTrace()[2].getClassName();

      // Remove the package info.
      if ( (className != null) && (className.lastIndexOf('.') != -1) )
         className = className.substring(className.lastIndexOf('.')+1);

      System.out.println(LOGGER_TIMESTAMP.format(new Date())+" "+className+": "+Thread.currentThread().getStackTrace()[2].getMethodName()+": "+data);
   }

   public static void main(String[] args)
   {
      MQListQueueAttributes01 mqlqs = new MQListQueueAttributes01();

      try
      {
         mqlqs.init(args);
         mqlqs.doPCF();
      }
      catch (IllegalArgumentException e)
      {
         MQListQueueAttributes01.logger("Usage: java MQListQueueAttributes01 -m QueueManagerName -h host -p port -c channel -u UserID -x Password");
         System.exit(1);
      }

      System.exit(0);
   }
}

Regards,
Roger Lacroix
Capitalware Inc.
